SPECIFICATIONS

TV format
Scanning system
Capturing element
Effective picture element : 440 K (VDC-C1572FP, VDC-C2572FP)
Synchronization system
Horizontal resolution
Video output level
Video S/N ratio
Minimum required
illumination
White balance (colour only) : Indoor/outdoor/push lock selectable manually
Backlight compensation
(BLC) function
Backlight compensation
iris level adjustment
Flickerless function
Gain control
Built-in lens
Manual angle of field
adjustment function
Downloaded from www.Manualslib.com
: Compatible with PAL TV format
: 625 TV lines, 50 fields/sec., 2:1 interlaced
: Interline transmission method, 1/3 inch CCD
fixed capturing element
290 K (VDC-B1512FP, VDC-B2512FP)
: Internal sync
: 460 TV lines (VDC-C1572FP, VDC-C2572FP)
380 TV lines (VDC-B1512FP, VDC-B2512FP)
: 1.0 Vp-p/75 Ω (BNC termination)
: 50 dB (VDC-B1512FP, VDC-B2512FP)
48 dB (VDC-C1572FP, VDC-C2572FP)
: 0.6 Lux (50IRE) (VDC-B1512FP, VDC-B2512FP)
0.4 Lux (30IRE) (VDC-B1512FP, VDC-B2512FP)
3.6 Lux (50IRE) (VDC-C1572FP, VDC-C2572FP)
1.8 Lux (30IRE) (VDC-C1572FP, VDC-C2572FP)
: ON/OFF selectable manually, center focus
separate photometry method
B/W cameras: ON only
: Manual V. R.
: ON/OFF selectable manually
B/W cameras: None
: ON/OFF selectable manually
B/W cameras: None
: Fixed lens F2.0, f= 4 mm
: Horizontal (pan) → 360° , Vertical (tilt) → 80°
manuals search engine
Operating environment : Temperature –10° C – +50° C
Humidity 90% RH or less
Storage environment : Temperature –20° C – +60° C
Humidity 95% RH or less
Power voltage/ : 12 V DC
Power consumption 1.5 W (VDC-B1512FP, VDC-B2512FP)
(Approx.)
2.6 W (VDC-C1572FP, VDC-C2572FP)
Weight (Approx.) : 1.3 kg (VDC-C1572FP, VDC-B1512FP)
0.7 kg (VDC-C2572FP, VDC-B2512FP)
: 139.7 (W) x 94.5 (H) mm, Dome 79.4 mm φ
Dimensions
Features and specifications are subject to change without
prior notice or obligations.
Approvals: IP66/CE
This camera has been certified to IP66 standards when
properly installed.
Use only an IP66 certified enclosure or an electrical box.
Ensure all openings in enclosure are sealed as per
manufacturer's instructions.
