Kytkentäkaavio 230V / 400V
wox d500
1 50Hz 230V 16A
L
230V
N
PE
1
21 1 3 5 A1
0
3
230V
U <
I
22 2 4 6 A2
2
gnge bl br sw ws rt
Komponentenliste:
1: Gehäuse K700
Z2 Z1 U2 U1
4
2: KB-04 Uc:230V~
mit Vorschaltöffner
3: Bremsplatine 230V~
4: Thermistor
5: Motor
16A
400V 3N 50Hz 400/230V
L1
L2
L3
N
PE
1
2
22 2 4 6 A2
0
400V~
U <
I
1 3 5
21 A1
3
br sw gr bl gnge
Komponentenliste:
1: Gehäuse K900
2: KB-04 Uc:400V~
V U W
mit Vorschaltöffner
3: Bremsplatine 400V~
4
4: Thermistor
5
5: Motor
Kytkentäkaavio 380-420V
ws 600/500 wox
L1
L2
L3
PE
1 3 5 13 A1
01
U
4 6
2 14 A2
P
21 20
U1 W1 V1
U2 W2 V2
M
3~ Bremse
Brake
Seite:28
Kytkentäkaavio 380-420V
wox d700
Kytkentäkaavio 220-240V
ws 500 wox
L1
N
PE
1 3 5 13
01
2 4 6 14
PE
20 21
<°C
Hi
CB
M Ha Z1
Z2
1~ U2 U1
1527 0041
General instructions
•After unpacking please check all parts for possible damage during transport. In case of complaints the driver needs to be
contacted as soon as possible.
•Complaints coming in later will not be recognized as such.
•Check if the consignment is complete.
•Familiarize yourself with the machine by means of the operating instructions before implementing it.
•In case of replacing worn or exchange parts, as for accessories, only use original Scheppach parts. You can obtain
exchange parts at the specialized dealer.
•Upon ordering, please specify our article nºs as well as type and year of construction of the tool.
Safety instructions
• In these operation instructions we have indicated positions that concern your safety, with this mark.
Training of the operator
• Forward the safety instructions to all people working on or with this machine.
• The minimum age for the operating person is 18 years. Trainees should be minimum 16 years of age, but are only
allowed to work with the machine under supervision.
• People running the machine should not be distracted.
• Keep children away from the to the net connected machine.
• Do not wear tight clothing. Take off jewelry, rings and wristwatches.
• Be careful at work: Danger of damaging finger(s) and hand(s) by the rotating cutting tool.
• Take notice of all safety and danger information of the machine and keep them readable.
Steadfastness
• Please be vigilant the machine is steadfast while being assembled.
1530 0109
Power supply line of the machine
• Check power supply lines. Do not use defective lines. See "Electrical connection".
• Pay attention to the motor and tool rolling direction. See „Electrical connection".
• Installations, repairs and maintenance installations to the electrical installation should only be carried out by experienced
staff.
• To repair disorders switch off the machine. Pull out the power plug.
• Upon leaving the work site switch of the motor. Pull out the power plug.
• Also at the slightest movement of the machine disconnect it from any external power supply! To restart orderly reconnect
the machine to the power supply!
Setting-up and adjusting of the machine
A1
• Setting-up, modifying, measuring as well as cleaning to be carried out only when motor is switched off. Pull out
U power plug and wait for stagnation of the rotating tool.
• All protection and safety facilities have to be assembled again directly after repair and maintenance works have
A2
finished.
• Use only well sharpened, slit free and non-deformed saw blades.
1527 0040
9322 0205 9322 0205
