Integrating The Appliance Into A Kitchen Unit - hanseatic HWC46GCIA Gebrauchsanleitung

Space required for installing the appliance under a worktop
J: 600 mm
N: 820 mm
L
K
3. Level out any unevenness on the ground
using both of the front screw feet.
– Close the glass door (1).
– Tilt the appliance backwards slightly and
screw in/unscrew the screw feet (3).
– Stand the appliance back up again and
check the alignment with a spirit level.
Repeat the process until the appliance
is standing up vertically. The appliance
should not move when opening the
glass door.
K: 575 mm L:
O: 520 mm P:
N
J
Integrating the appliance into
a kitchen unit
Risk of damage
If the ventilation slits are covered, the
heat from inside the appliance cannot
be properly expelled.
■
Start-up
825 mm M:
570 mm
M
O
NOTICE
Make sure that the ventilation slots
are not covered.
Page EN-21
595 mm
P
