NORAUTO RECOVERY Bedienungsanleitung Seite 139

Connecting the charger and charging the Battery with a Canbus socket
The unit can charge the battery on car with Canbus socket. Simply connect the charger connector on
the Canbus Charging Cord (sold by separately) to the unit's connector, and then connect the Canbus
connector on the Canbus Charging Cord to the Canbus socket on the car. Press the CHARGE button
to select 12V charging mode and charge as normal. Canbus charging process is for 12V battery only
DURING BATTERY CHARGING
Connect and setup the unit properly to start the charging.
If the Fault Icon
rings by respecting the polarity.
If the unit is connected to mains socket but the clamps/ terminal rings do not connect to the battery, the
LCD screen will display 12V Icon
CHARGING
1. After connect and set-up the unit, the LCD screen will display
empty battery icon
2. To indicate the unit is in charging mode, the charging current X.X
displays alternatively for every 3 seconds. And the LCD screen displays the
Icon, XX.X and the "+" Icon.
Hr
3. When the battery is completely charged, the charger will automatically go into Float Charge Mode,
and the LCD screen will display the 12V Icon
and the FLO Icon
* In this mode, the charger monitors the battery voltage and charges as necessary to assure the
battery maintains full capacity.
* The charger remains in Float Charge Mode as long as the charger is connected to the battery and
is plugged into a functioning AC mains socket.
4. Press any buttons during charging process, the unit will go to the corresponding mode.
ATTENTION:
a. If select the 24V charging mode to charge a 12V battery, the unit will do a self-check after few
minutes to confirm if it's a 24V battery. If the unit detects it is a 24V battery, keep 24V charging
process. If the unit detects it's a 12V battery, it will go to 12V charging mode, and flashes the 24V
Icon and the Fault Icon
b. If select the 12V charging mode to charge a 24V battery, the unit will change to 24V charging mode,
and flashes the 12V Icon
may keep charging at 12V charging mode but the battery will not be charged fully.
c. If the charger is overheated, the charging process will automatically terminate and the LCD screen
will flash the Overheat Icon
or the 24V Icon
Disconnect the charger and allow the charger to cool for several minutes. Make sure there is
adequate ventilation around the unit before attempting to charge again.
d. Temperature compensation: The
than 0°C. This is not a fault code, but indicates that the unit's temperature compensation feature is
operating.
lights up, unplug the charger from main power, and connect clamps or terminal
or 24V Icon
as well. After few seconds, the charging process will start automatically.
as well.
.
and the Fault Icon
and the Fault Icon
will light solid.
Icon will appear if the surrounding ambient temperature is lower
IMPORTANT
.
or 24V Icon
. If it is an internal short circuit 24V battery, it
, the empty battery icon
139
Icon or Icon, and the
and the battery voltage XX.X
A
, the empty battery icon
and the 12V Icon
V
,
