CONVERSION INSTRUCTIONS

CONVERSION INSTRUCTIONS
The appliance will have to be
converted for it to be able to run on
propane (G31).
This conversion may only be carried
out by a qualified installer, who will
also be able to order the required
conversion set.
Disconnect the gas supply before
converting.
Remove the burner unit and
the interior
To be able to change the required
elements, the complete burner unit
will have to removed and the interior
slid out of the casing.To do this:
• Remove the glass pane.
• Disconnect the gas supply pipe.
• Remove the vermiculite tray.
• Remove the burner tray.
• Remove the airflow regulator! This
does not have to be replaced.
• Remove the burner mounting plate
by unscrewing the self-tapping
screws (15), (fig.18a).
• Slide the interior out of the casing.
Changing the elements
1. Outlet connector (fig. 18b and 18c)
Break and remove the semi-circle
(23) of the connection (4).
2. Main burner jet (fig.18a)
Using an open-ended spanner
remove the jet with (16) and fit a
new one.
3. Oxypilot (fig.18a)
Disconnect the pilot light hose by
unscrewing the coupling nut (17).
Disconnect the ignition wire from
the electrode. Unscrew the thermo-
couple from the gas control block.
Remove the oxypilot by undoing
the 2 screws (18) and fit the new
oxypilot. Reconnect the pilot light
hose, the ignition wire and the
thermocouple.
16
Fig. 18a
23
Fig. 18b
6
15
17
18
4
