Fig. 18c
Fig. 19
4. Fine adjustment jet (fig.19)
Once the grub screw (19) has been
unscrewed, the fine adjustment jet
can be twisted out of the gas
control block. Fit the new fine
adjustment jet and then the grub
screw (19) in the gas control block.
Replacing the base set and
burner unit
• Apply the new type plate.
• Slide the interior back into the casing.
• Replace the burner mounting plate.
• Replace the burner tray without the
airflow regulator.
• Replace the vermiculite tray.
• Position either the logs or the white
carrara stones.
• Replace the glass pane.
• Fit the frame and front.
