3.2.2 Cooking zone display
On the displays relating to the cooking areas, the following is
indicated:
Cooking zone on
Power level
Residual Heat Indicator
Pot Detector
Bridge Function active
Temperature Manager Function
active
Pause function
Automatic Heat UP function
3.2.3 Hob features
• Safe Activation: The product is activated only in the presence of
pots on the cooking zone: the heating process does not start or is
interrupted if there are no pots, or if these are removed.
• Pot Detector: The product automatically detects the presence of
pots on the cooking zones.
• Safety Shut Down: For safety reasons, each cooking zone has a
maximum operating time, which depends on the maximum power
level set.
• Residual Heat Indicator: When switching off one or more cooking
zones, the residual heat is indicated with a specific visual signal on
the display of the corresponding zone by the " " symbol.
3.2.4 Operation
Note: activate the required zone first
• Switching on: Briefly touch
symbol will light up;
with a long press, all available functions will be visible for a few
moments, after which only the main ones will remain active; the
others may be used, and are activated subsequently during use
of the device.
Press ON/OFF (1) again to switch off.
• Selecting the cooking zones
Press (touch) briefly the Selection/Display (2) area corresponding to
the desired cooking area.
• Power Level
Touch and slide your fingers along the Selection bar (3):
to the right to increase the power level;
to the left to decrease the power level.
The power level set will be displayed in the Selection/Display
area (2)
There are 9 power levels available + an intensive power level
indicated on the display by the " " symbol (Power Booster).
... -
ON/OFF (1) hob/extractor: the
The " " power level (Power Booster) remains active for 5
minutes, after which the power returns to the previous level.
• Bridge Zones: The cooking zones FL ("Master") and RL
("Secondary") can work as a pair or in combined mode creating a
single zone thanks to the Bridge function with the same power
level. This function allows evenly distributed cooking with large-
sized pots and pans.
To activate the Bridge Function:
- select both cooking zones to be used simultaneously
- on the Display (2) of the "Secondary" cooking zone the " "
symbol appears
- using the Selection bar (3), it will be possible to set the
Operating power level, which will be shown in the Display (2) of
the "Master" cooking zone
- to disable the Bridge Function all you have to do is to repeat the
activation procedure
• Power Limitation
The Power Limitation function allows the product to be used while
limiting its maximum consumption.
Note : the setting must be carried out with the machine switched off,
without pressing the
hob is connected to the electrical system, or within 2 minutes of
reconnecting to the electrical system.
To set the Power Limitation:
- press
(which will flash, usually for the first 2 minutes after powering the
product on)
- continue to press and hold
time, of the Selection/Display (2) of the Cooking Zones in a
clockwise direction starting from the front right zone (FR)
- on each press a brief audible signal will sound
- once all of the Display (2) has been pressed, the
can be released:
15
ON/OFF (1) button, at the moment the
, press all the areas, one at a
button
