Page EN-24 Start-up
(20)
4. Pull the hinge plate (19) out of the plastic
insert (20) at the bottom edge of the glass
door.
(21)
5. Rotate the glass door 180° and place the
hinge plate (21) into the plastic insert (19)
here.
(23)
6. Unscrew the three screws (23) on the up-
per hinge (22) and remove it.
(24)
7. Unscrew the three screws (23) on the
lower hinge (24) and remove it.
(19)
8. Remove the 6 dummy plugs (25)
from the threaded holes above and below
and place them into the threaded holes
on the opposite side.
(19)
(22)
9. Screw the supplied upper hinge for the
(27)
(23)
(25)
(25)
(26)
(23)
left stop (26) using the screws (23).
(23)
