Figure 7 Connect the sample water and cooling water
1 Sample outlet
2 Cooling water outlet
3 Cooling water inlet
4
Instruments with the regenerative cooling option do not have a cooling water inlet or outlet.
16 English
4
4
4 Condensate drain (
steel)
5 Sample water inlet
3
/ -inch OD stainless
