Front Panel; Main Power Switch - LD Systems Premium Vue-Line SP1K8 Bedienungsanleitung

Ch-A
-6
-9
ICl
-3
PMS
-2
TeMP
-1
SgNl
-
0db
level
1 2
ON
ON
STbY
POwer
3
Ch-b
-6
-9
-12
-3 -12
-2
-1
-
0db
level
2 1
1
SIgNAl ATTeNUATION level CONTrOl kNObS
Permit independent control of each channel's attenuation
(21 steps).
2 SIgNAl - This LED indicates presence of signal at the inputs.
TeMP - This LED shows temperature protection is active.
PMS - LED indicating PMS in operation (see page 13).
ICl - LED indicating Intelligent Clip Limiter in operation
(see page 13 ).
3

MAIN POwer SwITCh

Position I: Connects the amplifier's current feed. (Blue LED on).
Position O disconnects the Power.
Position II (optional): Stand-by Mode. The Amp's Power is
activated remotely via Ethernet. (Amber LED).

FRONT PANEL:

Ch-A
-6
-9
ICl
-3
PMS
-2
TeMP
-1
SgNl
-
0db
level
1 2
Ch-b
-6
-9
-3
-2
-1
-
0db
level
2 1
5
