10 Spare parts list

10.1

Stem

see chapter Design, Pos. 3
Dimension Ball
valve
d20/50 – d32/50
d40/75 – d63/110
10.2

PE-connecting adaptor

see chapter Design, Pos. 14
Dimension Ball
valve
d20/50 – d25/50
d32/63
d40/75 – d63/110
10.3

Union end/ union bush

see chapter Design, Pos. 16
Dimension Ball
valve
d20/50 – d25/50
d32/63
d40/75 – d63/110
46
Code Quantity Dimension
748 410 103
749 410 103
748 410 027
749 410 027
Code Quantity Dimension
748 410 119
749 410 119
748 410 123
749 410 123
748 410 254
749 410 254
Code Quantity
748 410 111 2
749 410 111 2
748 410 249 2
749 410 249 2
748 410 258 3 (d63=4)
749 410 258 3 (d63=4)
2 3.54mm x 29.75mm
2 3.54mm x 29.75mm
2 3.54mm x 37.69mm
2 3.54mm x 37.69mm
2 5.34mm x 71.39mm
2 5.34mm x 71.39mm
2 5.34mm x 91.44mm
2 5.34mm x 91.44mm
2 7.0mm x 108.0mm
2 7.0mm x 108.0mm
Dimension
5.34mm x 104.37mm
5.34mm x 104.37mm
5.34mm x 123.19mm
5.34mm x 123.19mm
5.34mm x 146.1mm
5.34mm x 146.1mm
Spare parts list
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
