Instruction Manual
5.5

Assembling the CONTAIN-IT Plus Ball Valve Type 546

1. Move the protective housing over the
ball valve.
2. Plug the stem through the hole in the
protective housing onto the ball valve .
3. Please make sure that the stem is in
the right position. Therefore please
consider the outline of the stem and of
the ball valve.
4. Check if the stem is flush with the
bottom of the connecting element.
38
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Installation
