Control elements

Position indicator (page 27)
Symbolizes the position of the fitting.
LED radio display
Every operation of the optional remote control will be
acknowledged by a flashing of the radio display.
CLOSE
Check the position of the rotary lock - it needs to be locked.
Briefly push to close the drive.
OPEN to the tilting position
Check the position of the rotary lock - it needs to be locked.
Briefly push to move the drive to the tilting position.
OPEN to the turning position
Push for 1 s and the drive moves the window to the turning
position for normal, manual opening.
Unlock the rotary lock and open the window manually.
Lock the rotary lock after closing the window.
Timer-controlled ventilation
Check the position of the rotary lock - it needs to be locked.
Briefly push once to move the drive to the opening position.
After a ventilation time of 10 minutes, it moves back to the
closed position. Pushing the key again extends the
ventilation time by 10 minutes each time:
Pushed once: ventilate for 10 min.
Pushed twice: ventilate for 20 min.
Pushed three times: ventilate for 30 min.
Automatic/interval ventilation
Check the position of the rotary lock - it needs to be locked.
Briefly pushing the automatic key activates automatic or
interval ventilation. If this is activated, the room will ventilated
in the parallel opening position for 10 minutes every hour.
Info
Briefly pushing the key will light up the symbols and display
the current modes for 20 s when darkened.
Programming key (page 27 and 30)
