Scope of supply BDT-Advanced

The BDT-Advanced fitting drive and accessories for the BDT are available from
your D+H service and sales partner.
Please order the activPilot Ergo fitting system and the cable transition from
Winkhaus.
20/36
BDT-Advanced
a 1x Fitting drive
b 1x Base plate
c 1x Clamp (6 pole)
d 1x Fixing clip
e 1x Square shaft (7mm x 7mm) l=55mm
f 1x Lock washer
g 2x Countersunk screw M5 x 45 mm
h 1x Countersunk screw 4,1 x 19 mm
e
f
b
c
English
a
g
d
h
99.828.08 1.0/12/19
