Specifications - AKG MicroMic C 417 III Bedienungshinweise

Type:
Polar pattern:
Frequency range:
Sensitivity at 1 kHz:
Impedance:
Recommended load impedance:
Max. SPL for 1%/3% THD:
Equivalent noise level:
Power requirement:
Current consumption:
Cable length/Connector:
Finish:
Size:
Net/shipping weight:
This product conforms to EN 50 082-1 provided it is connected to
equipment with a CE mark.
Frequency Response
Downloaded from www.Manualslib.com manuals search engine

6 Specifications

pre-polarized condenser microphone
omnidirectional
20 Hz to 20,000 Hz
10 mV/Pa (-40 dBV re 1 V/Pa)
200 Ω
≥2000 Ω
118/126 dB SPL
34 dB (A) (to DIN 45412)
III
C 417 PP: 9 to 52 V universal phantom power
III
C 417 L/PL: B 29 L battery power supply,
MPA III L phantom adapter, or
AKG WMS bodypack transmitters
approx. 2.2 mA
III
C 417 PP: 3 m (10 ft.) / 3-pin male XLR
III
C 417 L/PL: 1.5 m (5 ft.) / 3-pin mini XLR
matte black (PP, L) or flesh-color (PL)
7.5 x 15 mm (0.3 x 0.6 in.)
III
C 417 PP: 8 g (0.3 oz.) / 220 g (7.8 oz.)
III
C 417 L/PL: 8 g (0.3 oz.) / 160 g (5.6 oz.)
Polar Diagram
23
