CAUTION!
- Ensure that the monitor and all the equipment you are connecting to it are switched off before you
begin.
AV equipment with 21-pin Euro-SCART (RGB) terminals
Left side of the monitor
AV equipment with video output terminals
Left side of the monitor
Note:
- When you are using the video input terminal, do not connect the cable to the S-video input terminal.
Downloaded from
www.Manualslib.com
Connecting the monitor to AV equipment
AV-IN1
21
19
17
15
13
11
AV-IN2
manuals search engine
21-pin Euro-SCART cable
(commercially available)
20
18
16
14
12
10
9
8
7
6
5
4
3
2
1
(Yellow)
(White)
(Red)
RCA pin cable (commercially available)
E12
Decoder etc.
VCR etc.
(Yellow)
(White)
(Red)
