ADJUSTMENT menu

Item
AUTO
CLOCK
PHASE
H-POS, V-POS
RESET
Downloaded from www.Manualslib.com
Adjusting the display
Description
Automatically adjusts "CLOCK", "PHASE", "H-POS", and "V-POS".
(See page E17.)
Adjusts the clock so that no vertical flicker noise is emitted.
Vertical flicker noise
Makes an adjustment after "CLOCK" is properly adjusted so that no
horizontal flicker noise is emitted.
Horizontal flicker noise
Adjusts the position of the Adjustment Pattern so that it appears centred
on screen.
Adjustment
Pattern
Resets adjustment values for this menu to their original factory settings.
manuals search engine
Screen frame
E23
