Connecting the monitor and turning

Connecting the monitor to a power source

Use only the AC adapter supplied.
Note:
- Do not overly bend the cable or add extension
cords as this could lead to malfunction.
1. Remove the stand cover.
(Rear View)
2. Remove the cover.
Cover
3. Connect the AC adapter to the monitor's power
terminal.
Power terminal
Place cord
on hook
4. Replace cover.
Cover
the monitor on and off
Stand cover
Lift one side
Run cord
through hole.
AC adapter
12
5. Connect power cord to AC adapter.
Fitting the AC adapter inside the stand
Wind the cord
Place adapter inside
stand cavity.
6. Replace stand cover.
1
7. Place power plug into AC outlet.
Power cord
Stand cover
2
1
