Parts List - reer S-Gate Montageanleitung

Screwed gate S-Gate
EN
Instructions

Parts list

a
1x Gate compartment A 1x Gate compartment B 2x Adjustment screws
e
2x Cover - bottom
i
2x Upper hinge part
n
1x Hinge support B
necessary
tools
// Art.No. 46110
b c
f g
2x Cover - top 2x Mounting clamp
k l
8x Screw sleeve
8x Wood mounting screw
o p
2x Stopper 1x Wrench
- 7 -
d
2x Hinge bolts
h
2x Lower hinge part
m
1x Hinge support A
q
1x Mounting template
