2.2.7 Chlorine extraction

Before the extraction
The chlorine containers must be stored at least for 8 hours in
the container room so that the content can adapt the ambient
temperature.
Warning
Chlorine containers must never have a higher
temperature than other parts of the plant. Danger of
liquefaction and possible chlorine break-out!
Turn chlorine drums on the support until the dip pipe and the
riser pipe are placed vertically (observe the markings on the
drum).
Check tightness.
Connection
Protect containers from turning over or rolling away!
Dry the piping and the withdrawal system with dry nitrogen or
dry air.
No foreign matter must get into the plant.
Mount new gaskets to the connection line.
Connect the container.
Slowly open the container valve.
Withdrawal of gaseous chlorine
At 15 °C about 1 % (DIN19607) of the content can be
withrawn per hour. In case of higher withdrawal
Caution
danger of malfunction by the formation of ice on
containers and piping!
Container size
50 Kg
65 Kg
500 Kg
1000 Kg
In case of higher chlorine requirement several chlorine containers
of the same temperature have to be connected with header lines.
Withdrawal of liquid chlorine
Within chlorination plants only possible from chlorine drums.
Application of an evaporator is necessary.
Do not completely evacuate the chlorine drums.
Caution
Danger of withdrawing deposits!
Withdrawal of gaseous chlorine: Observe residual pressure of
ca. 2 bar.
Withdrawal of liquid chlorine: Observe residual pressure of ca.
4 bar.
After the extraction
Close container valve.
Disconnect container from the plant.
Screw on valve protection nuts.
Screw on protection cap.
Immediately close connection lines.
Caution
No moisture must get into the lines!
8
Withdrawal quantity
500 g/h
650 g/h
5 Kg/h
10 Kg/h

2.3 Checking the tightness

Before commissioning check the tightness of the whole plant.
Warning
Do not check the tightness until the whole plant is
ready for start-up.
Danger of chlorine break-out!
2.3.1 Checking the chlorine solution lines and the diaphragm
non-return of the injector
Observe the manual of the injector!

2.3.2 Checking the tightness of the vacuum lines

Vacuum lines are all lines between vacuum regulator and injector.
Close all container valves
Close the rate valve
Open the shut-off valve at the injection unit
Open motive water valve
Switch on the booster pump
Open the rate valve
– Floater shows gas flow or vacuummeter shows more than -
9 m w. c.: Leakage in vacuum line!
Close rate valve
Switch off booster pump
Close motive water valve
Close the shut-off valve at the injection unit
Check the vacuum lines and the connection. If necessary,
carefully re-tighten them.
Check tightness again!
– Floater shows no gas flow, vacuummeter shows -9 m w. c.
or less: Vacuum lines are tight.
More possible reasons for insufficient operating
vacuum
injector layed out too weakly or defective
Note
injector obstructed
booster pump layed out too weakly or
defective

2.3.3 Checking the tightness of pressure gas lines

Pressure gas lines are all lines from the gas containers to the
vacuum regulator.
If the plant is equipped with a nitrogen rinsing device: Check
tightness roughly with nitrogen
Detailed checking with ammonia
Checking the tightness with nitrogen
Close all container valves
Open container connection valves and all shut-off valves up to
the gas dosing system
Open the connection valve of the nitrogen cylinder
Slowly open the valve of the nitrogen cylinder, until the lines
have a pressure of about 10 bar (read at the manometer of
the vacuum regulator).
Warning
Maximum nitrogen pressure 16 bar!
Danger of damages and gas leakage when being
exceeded!
Apply soap water to all components under pressure
– Formation of bubbles and/or pressure drop at manometer
Leakage in pressure lines!
– Depressurize the plant!
– Eliminate leakage!
– Check tightness again!
No formation of bubbles, pressure at manometer does not drop
significantly within one hour: Pressure lines are tight.
Checking the tightness with ammonia
See chapter
5.2.2 Checking the
tightness.
