3.3 Dimensioned drawings

3.3.1 Dosing regulator

Fig. 13 Dosing regulator

3.3.2 Dosing regulator with servomotor

Fig. 14 Dosing regulator with servomotor
14
236
~ 82
~ 260
~ 92
120
~ 140
72.5
120
~ 140
72.5
