AXP-100H MUSCLE
AM4/AM2/AM2+/AM3/AM3+/FM1/FM2/FM2
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
M3 L17 Screw
TY-100BW Fan
Heatsink Body
M3 L6 Screw
Anchoring Mount
Mounting Plate
Screw Nut
AMD Washer(big)
Backplate cap
Mylar Film
Metal Back Plate
M3 L10 Screw
5
