Monitor care

Always remove the plug from the AC outlet when
cleaning the monitor.
Cabinet and control panel section
Use a soft dry cloth to lightly wipe away any grime
from the cabinet and control panel.
If they are very dirty, apply neutral detergent to a
dampened soft cloth, wring it out well and wipe
away grime.
LCD panel section
Use a soft dry cloth to lightly wipe away dirt and
dust from the surface of the LCD panel. (A soft
cloth such as gauze or that used for lens cleaning
is suitable.)
CAUTION!
- Never use thinner, benzine, alcohol, glass
cleaner, etc, as this could lead to color change or
change in shape.
- Never scratch the monitor with anything hard or
apply strong pressure as this could leave marks
or result in malfunction.

Storage

If the monitor will not be used for a long period of
time, be sure to remove the power plug from the
AC outlet.
CAUTION!
- Do not leave the monitor in contact with rubber or
plastic items for long periods of time as this could
lead to color change or change in shape.

Troubleshooting

If you think the monitor may be faulty, please check
the following points before taking it to be repaired.
If afterwards it still does not work, please contact
the shop where you purchased the monitor or your
nearest Sharp authorized Service Center.
The monitor's florescent tubes have a limited
life span.
- If the screen darkens, persistently flickers or
does not light up, it may be necessary to
replace the florescent tube unit. Please
inquire at the shop where you purchased the
monitor or your nearest Sharp authorized
Service Center. (Never attempt this
replacement on your own.)

Monitor care and repair

22
- In the initial period of use, due to the
characteristics of florescent tubes the screen
may flicker. (This is not a malfunction.)
Should this happen, check by first turning off
the power, then turning it on again.
No image appears on the monitor (Power LED is
not lit)
- Are the AC adapter and the power cord
connected properly? (p. 12)
No image appears on the monitor (Power LED is lit)
- Is the computer connected properly? (p. 11)
- Is the computer turned on?
- Is the signal's input terminal switched to the
correct one? (p. 13)
- Does the computer's signal timing correspond to
monitor specifications? (p. 24)
- Is the computer in power-saving mode?
Control buttons do not work
- Is the adjustment lock on? (p. 14)
The image appears distorted
- Does the computer's signal timing correspond to
monitor specifications? (p. 24)
- If you are using the analog signal, perform
automatic screen adjustment. (p. 16)
- If you can change the refresh rate on the
computer you are using, change the value to a
lower frequency.
No sound can be heard from the speakers
- Is the audio cable connected correctly? (p. 12)
- Perform the volume adjustment procedure.(p. 15)
- Are the headphones connected?
- These is no sound from the speakers when the
monitor is in power-saving mode.
When attempting to raise the display section, it
is found hard to lift.
- Be sure to press the lock disable button while
folding back the monitor.
If this is not done it will become hard to lift the
monitor next time.
- If you forget to press the lock disable button while
folding back the monitor, lift the monitor forward
to the limit of its travel (approx.5°). Then while
pressing the lock disable button, gently fold back
the monitor again.(p. 10)
