Adjusting the screen display
MODE SELECT Menu
MODE SELECT
OS D H-POS I T I ON
OS D V -POS I T I ON
S C AL I NG
I N P U T
4 0 0 L I NE S
L A NGUAGE
I N P U T - 1 A N A L O G
1 2 8 0 x 1 0 2 4 V : 6 0 H z
Notes:
- Depending on the resolution of the input signal,
even if menu options can be selected, the display
may not change.
- To choose a menu option:
- To complete adjustment: MENU button
OSD H-POSITION (OSD horizontal position)
The position of the OSD Menu can be moved to the
left and right. ( buttons)
OSD V-POSITION (OSD vertical position)
The position of the OSD Menu can be moved up
and down. ( buttons)
SCALING (Level of scaling)
The sharpness of the image can be adjusted. (
buttons)
Note:
- When the display mode is set to less than
1280 x 1024 pixels, the display is enlarged to
cover the whole screen (i.e. the side ratio of the
display may change).
INPUT
When connecting a Power Macintosh, set to [MAC].
( buttons)
400 LINES (degree of resolution)
You can specify the horizontal resolution of a 400-
line screen when using US text, etc. (
640: 640 X 400 dot mode
720: 720 X 400 dot mode (US text etc.)
Note:
- As the resolution input for other than 400 lines is
done automatically, there is no need to set it.
LANGUAGE
You can choose the language used in OSD Menu.
1. Press the button.
The Language Selection Menu will be displayed
on the screen.
2. Use the / MODE button to choose a language.
3. Press the MENU button.
Language Selection Menu will disappear.
3
VESA MAC
640 720
H : 6 4 . 0 k H z
/ MODE button
buttons)
19
(When using an analog signal)
