H55.0.01.6C-02
III.) Sea Level Correction "SEA.L" (Sea Level) Of Barometer Display:
The sea level correction corrects the measured pressure to the pressure value above sea level (zero altitude)
9. Press 'Mode' or 'Zero' key, the currently selected state of the sea level correction will be displayed
10. Enter the desired state by pressing 'Mode' or 'Zero' key.
selectable values are:
11. Confirm with 'On/Off'-key: SEA.L = on: 'Alti' appears in the display
IV.) Entering the Altitude For The Sea Level Correction „Alt":
Here the current elevation above sea level has to be entered.
12. Press 'Mode' or 'Zero' key, the currently selected elevation for the sea level correction will be displayed.
13. Enter the desired state by pressing 'Mode' or 'Zero' key.
selectable values are:
14. Confirm the value by pressing 'On/Off' key: 'tEnd' appears in the display.
V.) Tendency Display For Barometer
15. Press 'Mode' or 'Zero' key, the currently selected state of the tendency display will be displayed.
16. Enter the desired state by pressing 'Mode' or 'Zero' key.
selectable values are:
17. Confirm the value by pressing 'On/Off' key.
18. The values will be stored, the instrument will restart (segment test).
Please note: If during the configuration no key is pressed within 20 seconds, the configuration will be
aborted. Eventually made changes won't be stored!
Offset and Scale Adjustment (for "temp" and "baro")
The offset and scale adjustment is intended to be used to compensate errors of the internal pressure and temperature
sensors. The display value is given by following formulas:
Unit = °C, mbar, mmHg:
Unit = °F:
To adjust a measuring offset and scale proceed like follows:
1. Switch off the instrument. Set Slide Switch to „baro" or „temp", whichever to be corrected.
2. Press the 'Zero' key while switching on the instrument, keep 'Zero' key pressed until 'OFFS' appears (after about 3
seconds).
3. Press 'Mode' or 'Zero' key, the currently selected offset adjustment appears.
4. Choose the desired value by pressing 'Mode' or 'Zero' key. (max. input range: ±5mbar or ±5.0°C resp. ±9.0°F)
5. Enter by pressing On/Off-key: SCAL appears in the display
6. Press 'Mode' or 'Zero' key, the currently selected scale adjustment appears
7. Choose the desired value by pressing 'Mode' or 'Zero' key. (max. input range: ±5.00%) The input is displayed in %.
example: scale adjustment is 1.00 => scale is increased by 1.00% => Scale = 101%
At a measured value of 1000.0 (without offset correction) the instrument would show 1010.0
8. Store the values by pressing 'On/Off' key. The instrument will restart (segment test).
Please note: If during the changing of the offset adjust no key is pressed within 20 seconds, the input will be
aborted. Eventually made changes won't be stored!
System Messages
Er. 1
= measuring range has been exceeded
Er. 2
= meas. value has fallen below perm. range
Er. 3
= display range has been exceeded (>9999)
Er. 4
= meas. value has fallen below displayable range
Er. 7
= System fault - the device has detected a system fault (defective or far outside allowable ambient
temperature range)
Err.11 = Sensor error or value could not be calculated
If the symbol "LO BAT" is displayed at the left side of display, the battery is weak, measuring can be continued for a
certain time.
If "bAt" is displayed in the main display the battery is used up and needs to be replaced. Measuring is no more
possible.
on / off : sea level correction activated / deactivated
SEA.L = off: 'tEnd' appears in the display
-500... 9000m oder –1640 ... 19999ft
on / off: tendency display activated / deactivated
Display = (measured value - offset) * ( 1 + scale adjustment [%] )
Display = (measured value –32°F - offset) * ( 1 + scale adjustment [%] )+32°F
(<-1999)
page 4 of 4
