OVERVIEW FUNCTIONS

1. Big LCD display; channel no. / frequency and various functions
2. AM / FM / USB / LSB mode
3. Frequency Tuning Step can be 10HZ, 100HZ, 100Khz,1MHz
4. ± 1.5KHz Clarifier
5. Menu functions PC programming software
6. ECHO Function
7. SQ, ASQ Function (FM and AM mode only)
8. RF GAIN Adjustment
9. RF PWR Adjustment
10. SCAN Function
11. Programmable RB Function
12. NB/ANL Function
13. DW DUAL-WATCH Function
14. BEEP Voice Prompt
15. +10KHZ Function
16. SWR, S/RF function
17. TOT function
18. HI-CUT Function
19. EMG CALL, priority channels
20. SWR PROTECTION
21. Power Supply Voltage Protection
22. Key-Lock Function
23. 7 LCD colors
24. 10 memory banks with 40 channels each (programmable via software)
25. PC programming with optional software
22
Base the decision about the position of the HAM MobileCom 1011 in your vehicle on the aspect of safety. No part of the
setup, i.e. radio, microphone, cable, etc., should restrict or obstruct the driver or passenger in any way.
U-bracket holder
1. Mount the U-shaped bracket holder with the threading screws and the washers
at the desired location in the driver cabin.
2. Mount the radio onto the bracket holder with 2 adjusting screws and rubber
pads in the rear holes of the bracket holder.
3. Set the desired angle of the radio at the bracket holder and fix the angle with the remaining adjusting screws and rubber pads.
microphone holder
1. Mount the microphone holder with the two threading screws onto the desired location in the vehicle.
2. Plug in the 6-pin micrphone connector into the front jack (16), located on the left side of radio. Tighten the retaining
screw of the microphone plug.
antenna
The antenna should be matched with the radio, otherwise a part of the transmit power will be reflected in the antenna
and will not be radiated. This will reduce the range of operation. Since the antenna is one of the most important links in
the setup, the following criterias are very important.
General :
> The frequency range of the antenna has to cover the programmed frequencies on the radio.
> The positon of the antenna should be as elevated and unobstructed as possible.
> Ensure that the cable and the connector of the antenna are intact and that the plug is connected properly.
> Ensure that the cable is not bend too much.
> The length of the antenna rod and the range of operation are related. The longer the rod, the further the distance.
Upon antenna-mounting, the following has to be considered :
> The antenna should be placed in the middle of a vehicle part.
> The antenna base should have good contact to a metal, conductive surface of the vehicle.

SETUP
