MOUNTING
Use only high quality proximal endoskeletal components. Use of mounting fasteners other
than those provided will void the warranty.
ASSEMBLY AND DISASSEMBLY
Use the Foot Horn to don and doff the foot shell. Remove the CPI Sock and replace as needed.
Any further disassembly or modification of components will void the warranty.
STATIC ALIGNMENT
For optimal function have the patient's weight balanced between the forefoot and heel.
The load line divides the foot at 1/3 heel lever.
DYNAMIC ADJUSTMENTS
DESIRED RESULT
Firmer Toe Response
Softer Toe Response
Firmer Heel Response
Softer Heel Response
MOUNTING FASTENER GUIDELINES
Fastener length will vary with adapter choice. M6 x 16mm fasteners are for use with rotatable
adapters, while M6 x 14mm fasteners are for use with non-rotatable adapters.
FASTENER SELECTION
Thread length too short
Thread length too long
CAUTION
Apply Loctite 242
® ®
▪
Torque evenly to 12 N∙m (8.8 ft-lbs).
▪
Failure to follow these guidelines may result in one or all of the following: noise, movement, damage, and
catastrophic failure.
EXPOSURE TO MOISTURE
To maintain the lifespan of the Enviroshell
to moisture. Rinse and dry if exposed to salt water or chlorinated water.
WARNING
Failure to follow these technical instructions or use of this product outside the scope of its Limited
Warranty may result in injury to the patient or damage to the product.
ALIGNMENT CHANGE
Plantarflex the Soleus or move load line posterior
Dorsiflex the Soleus or move load line anterior
Dorsiflex the Soleus or move load line anterior
Plantarflex the Soleus or move load line posterior
POTENTIAL RESULT
Inadequate thread engagement
Bottoming-out or binding
on all 4- hole fastener threads.
and CPI sock, always dry foot thoroughly after exposure
®
(for sock replacement)
