Ethernet/IP™ Klassen SAI-AU
8.1 Übersicht allgemeine Klassen
Class Class Name
01 Idendity Object
H
04 Assembly Object
H
F5 TCP/IP Interface Object
H
F6 Ethernet Link Object
H
8.2 Übersicht geräte-spezifische Klassen
SAI-AU M12/M8 EIP 16 DI
Class Class Name
08 Discrete Input Point Object
H
65 Vendor Specific Desina Ob-
H
ject
SAI-AU M12/M8 EIP 16 DI/8DO
Class Class Name
08 Discrete Input Point Object
H
09 Discrete Output Point Object
H
65 Vendor Specific Desina Ob-
H
ject
66 Vendor Specific IO Switch
H
Object
64
Instances Instance Name
1 Instance Attributes Idendity Object
0 Class Attributes Assembly Object
100 Instance Attributes Assembly Object Input
101 Instance Attributes Assembly Object Output
128 Instance Attributes Assembly Object Configura-
tion
0 Class Attributes TCP/IP Interface Object
1 Instance Attributes TCP/IP Interface Object
0 Class Attributes Ethernet Link Object
1 Instance Attributes Ethernet Link Object
Instances
0
1..16
1..8
Instances
0
1..16
0
1..8
1..8
1..8
Instance Name
Class Attributes Discrete Input Point Object
Instance Attributes Discrete Input Point Object
Instance Attributes Desina Input Object
Instance Name
Class Attributes Discrete Input Point Object
Instance Attributes Discrete Input Point Object
Class Attributes Discrete Output Point Object
Instance Attributes Discrete Output Point Ob-
ject
Instance Attributes Desina Input Object
Instance Attributes IO Switch Object
