Functions and features
● The freely programmable controllers of the "ecomatController" series are rated
for use under difficult conditions (e.g. extended temperature range, strong
vibration, intensive EMC interference).
● They are suited for direct installation in machines in mobile and robust applica-
tions. Integrated hardware and software functions (operating system) offer high
protection for the machine.
WARNING
The safety functionality is in preparation. At present the device has NO safety
functionality! Once the firmware is certified, the corresponding hardware can also
be used for safety-related applications. This is possible under the following condi-
tions:
• Firmware update with the certified version
• Observance of the operating / programming manuals that are applicable for
the firmware
• Adjustment of the safety-related parts of the application program
WARNING
The user is responsible for the safe function of the application programs which
he created himself. If necessary, he must additionally carry out an approval test
by corresponding supervisory and test organisations according to the national
regulations.
Installation
Fix the controller to a flat surface using 4 galvanised M6 screws. Tightening tor-
que: 10 ±2 Nm. Do no use stainless steel screws or nickel-plated screws! In very
corrosive environments such as extremely salty air, we recommend to use screws
with surface finishing on a zinc/nickel basis with thick-film passivation and sealing.
Set-up
Only qualified staff is allowed to set up the device.
Furthermore we expressly point out that any liability is excluded if the notes in the
programming and set-up documents are not adhered to.
For the set-up of the device the following components are needed:
Hardware
● PC/notebook and Ethernet interface
(e.g. connection cable, article no.: E11898 or E12226)
● Connection cable, article no.: EC0710, EC0711, EC0720 or EC0721
Software and documentationen
● Installation instructions and programming manual ecomatController
● Programming system CODESYS V3.5 SP11
● TFTP client for updates (optional)
