6.7 POKER CONNECTION TO FLEXIBLE SHAFT

The flexible shafts TAX are intended to connect the pokers: AX38, AX48 and AX58.
Allowing to interchange of a poker to other quickly and without a special tool. The model AX25, due to the
diameter need a special transmission. (TAXE).

6.8 INSPECTION

7
AVMU MOTOR - FLEXIBLE SHAFT AND POKERS
Downloaded from www.Manualslib.com
CONNECTION PROCEDURE:
1-Introduce the hexagonal driver of the poker in the shaft.
2-Screw the poker on the screwed end of the transmission up to fasten with the hand. ( left
threads).
1.Before starting the job , check the correct working of all handling and safety devices
2.Inspect regularly the good condition of the feeding cables
3.Inspect regularly the good condition of the transmission. When the hose is broken, repair it or
replace it to avoid damaging the shaft or the poker.
4.When notice wear parts, replace it.
5. If defects are found in the safety devices or other defects which could reduce the safe handling
of the equipment, notify immediately to proper responsible person.
DIMENSIONS OF WEAR FOR DIAMETERS AND LENGTHS OF
THE POKERS
MODEL DIAMETER
(mm)
AN 25 23,5 (25)
36 (38)
AN 38
AN 48 45,5 (48)
67,5 (70)
AN 70
AX 25 23,5 (25)
AX 38 36 (38)
45,5 (48)
AX 48
AX 58 55,5 (58)
23,5 (25)
PNU 25
PNU 40 38 (40)
PNU 50 47,5 (50)
57,5 (60)
PNU 60
PNU 80 77,5 (80)
97,5 (100)
IN 100
M35 AFP 34,5 (36)
M5 AFP 48 (50)
M6 AFP 56 (58)
M7 AFP 64 (66)
TAX1m, TAX1-5m, TAX2m, TAX3m, TAX4m, TAX5m
manuals search engine
MINIMUM SECTION ACCORDING VDE RULES
Line Maximum
mm²
1
1,5
2,5
4
6
10
16
25
LENGHT
(mm)
325 (330)
351 (356)
424 (429)
510 (518)
310 (220)
330 (335)
355 (360)
360 (365)
215 (220)
295 (300)
295 (300)
295 (300)
340 (345)
425 (430)
345 (350)
370 (375)
425 (430)
395 (400)
AVMU - AX25, AX38, AX48, AX58
Max fuse
A A
15 10
18 10 / 3 – 16 / 1 –
26 20
34 25
44 35
61 50
82 63
108 80
