Performing Current Measurements
To perform current measurements, set up your
multimeter as shown in the figure below. For
measuring DC current from a mixed signal in DC
measurement mode, ensure that the Filter is
enabled.
Measuring AC current
1 Set the rotary switch to
Press
display.
2 Connect the red and black test leads to input
terminals µA.mA (red) and COM (black) or A
(red) and COM (black) respectively.
3 Probe the test points in series with the circuit
and read the display.
Keysight U1253B Quick Start Guide
manuals search engine
or
to ensure is shown on the
.
11
