Range of settings for the
manual mode
Arcing -10 to 10 (default value 0)
Penetration 10 to 60 A
and cleaning
0 to 200 ms
Arc 0 to 350 A
0 to 800 ms
Attachment -10 to 10 (default value 0)
0 to 50 ms
Height 0.5 mm to 5 mm
CONFIGURATION
Configuration
> Pregaz > 0.2s
Postgaz 0.2s
Langue FR
Reset machine
Info
Range of settings
Pregas NoGas then from 0.2s to
3s
Postgas NoGas or from 0.2s to 3s
Language FR, GB, DE, NL, ES, IT, RU
Push the return button
Reset machine
Reset machine
: 3sec
pour valider
Information panel
Info machine
Soft géné V1.0
Hard géné V2.0
Soft pistolet V1.0
Hard pistolet V2.0
26
GYSPOT ARCPULL 350
Comment
"The default value is set to ensure optimal arcing and stop the arc
from breaking up when pulling the insert while limiting the short-
circuit current.
Slightly increase the ignition in case of repeated arcing failures. "
Limited to 100A if product is connected to a 110Vac ±15% power
supply
The default value is set to ensure optimal attachment of the elec-
trode onto the metal support.
Press the keys G+ and G- to move the left cursor (Pregas, Postgas, Language, Reset
machine, Info).
When the items Pregas, Postgas or Language are highlighted, press the keys D+ and D-
to modify their value.
Comment
To weld using a gas coating, it is recommended to have a minimum pre-
gas setting of 0.2s with a flow rate between 10 and 12L/min.
To weld using a gas coating, it is recommended to have a minimum
postgas setting of 0.2s.
to return to the Main Menu
When the «Reset Machine» is selected from the Configuration menu, pressing menu/vali-
date opens the reset machine sub-menu.
Press menu/validate
Push the return button
The information panel provides information on software versions and hardware of the gene-
rator and gun (if it is connected).
for 3 seconds to confirm product reset.
to return to the Configuration menu and cancel product reset.
