Bosch PLR 30 C Originalbetriebsanleitung Seite 29

above it. Pressing the measuring button (4) once more will start the continuous meas-
urement again.
Continuous measurement automatically switches off after four minutes.
Deleting measured values
In any measuring function, you can delete the most recently recorded individual meas-
ured value by briefly pressing the on/off button (8). Repeatedly pressing the button
briefly will delete the individual measured values in reverse order.
Adding/subtracting values
Measured values or end results can be added or subtracted.
Adding values
The following example describes the addition of areas:
Measure an area as described in the section on area measurement (see "Area measure-
ment", page 28).
To subtract values, press the button (7) [–]. The subsequent steps are the same as for
the section on adding values.
Bosch Power Tools
Downloaded from www.Manualslib.com
Press the measuring button (4) to initiate the measuring process.
Move the measuring tool until the required distance value is shown at
27.589 m
min the bottom of the display.
29.589 m
max
You can pause the continuous measurement by pressing the measur-
ing button (4). The current measured value will be shown at the bot-
28.000 m
tom of the display. The largest and smallest measured value appear
Press the button (1) [+]. The calculated area is shown in the centre
of the display.
+4.324 m
2
0.000 m
2
Press the measuring button (4) to start another area measurement.
Measure the area as described in the section on area measurement
+5.523 m
2 (see "Area measurement", page 28). To complete the addition, press
+4.324 m
2
the measuring button (4). To add more measured values, press the
button (1) [+] again and repeat.
9.847 m
2
Subtracting values
manuals search engine
English | 29
1 609 92A 4P0 | (18.01.2019)
