(4)
(5)
(6)
(7)
(8)
(9)
(10) Locking mechanism of the battery compartment cover
(11) Serial number
(12) Reception lens
(13) Laser beam output
(14) Laser warning label
(15) Laser viewing glasses
(16) Laser target plate
(17) Protective bag
A) Accessories shown or described are not included with the product as standard. You can
Display elements
(a) Bluetooth® status
(b) Battery indicator
(c) Measured value
(d) Result
(e) Laser switched on
(f) Reference level of measurement
(g) Measuring function
(h) Error indicator
Bosch Power Tools
Downloaded from www.Manualslib.com
Measuring button [ ]
Colour display
Reference level selection button
Minus button [–]
On/off button [ ]
Battery compartment cover
A)
A)
find the complete selection of accessories in our accessories range.
Bluetooth® activated, no connection established
Bluetooth® activated, connection established
Length measurement
Continuous measurement
Area measurement
Volume measurement
