Sirona HELIODENT DS Kurzgebrauchsanweisung Seite 2

HELIODENT DS
I 0
ON OFF
1
Bring main switch (1) into position I.
The unit is ready once the Ready LED lights up.
Set up the X-ray head.
__________________________________________________________________________________________________________________________________________________
Downloaded from www.Manualslib.com
Concise Operating Instructions
LED
Briefly press the D button to select the radiographic
technique (conventional or digital).
Angle of inclination of the cone to the occlusal plane.
manuals search engine
Digital
Angle of inclination
Molars
Premolars and canine teeth
Front teeth
Occlusal exposure
Occlusal exposure
Front teeth
Premolars and canine teeth
Molars
Set the exposure data:
Set the patient symbol
to the tooth to be X-rayed. The associated exposure
time is indicated.
X-ray
LED
+ 35°
+ 45°
+ 55°
+ 80°
– 90°
– 20°
– 10°
– 5°
CAUTION: Observe radiation protection regulations!
Release exposure by keeping the release button held
down. The X-ray radiation indicator lights up.
An acoustic signal sounds.
child or adult
i i i i
Release button
41 62 959 D3302
