2.
Function of the flash light
2.1. Switch on
To minimize power up the activation of the flash circuit is at the zero crossing of the mains phase.
2.2. The modes of operation
With the dimmer value bit7 and bit6 an operating mode of the flash light is chosen.
Betriebsart
No function
Fixed flash
Random flash
Controlled
flash
2.2.1.
Dimmer value 0..63.
In this mode no flash is produced.
2.2.2.
Dimmer value 64..127.
In this mode a flashing light is generated independent by the flashlight at a fixed interval.
With the dimmer value bit0..bit5 the flash generation can be set in 64 steps between 0.5 s and 6.8 s.
Formula to calculate the flash sequence:
Example:
The dimmer value
t
= (5 + 78 - 64) * 0.1sec
Flash
t
= (19) * 0,1sec = 1.9sec
Flash
A flash is produced every 1.9 sec.
2.2.3.
Dimmer value 128..191.
In this mode a flashing light is generated independently by the flashlight at random intervals.
The random interval consists of a constant and random component.
The random component can be expanded by an additional constant part.
The result is random flash generation between 0.5 sec and 30.5 sec.
With the [dimmer value bit2..bit0] the random component is extended. Values: 0..15
With the [dimmer value bit5..bit3] the constant component is determined. Values 0..15.
Margin: Random number. Value: 0..15
Formula to calculate the flash sequence:
t
= (5 + 5 * [Dimmer value bit5..bit3] + random value* [Dimmer value bit2..bit0]) * 0.1sec.
Flash
Example:
The dimmer value
t
= (5 + 5 * [010
Flash
t
= (5 + 5 * 2 + random value * 4) * 0.1sec
Flash
The constant spacing is therefore: (5 + 5 * 2) * 0.1sec = 1.5sec.
The random part is expanded 4-fold.
The random time intervals are therefore: (0..15 * 4) * 0.1sec = 0..6sec.
The random total spacing of the flashes is therefore between 1.5 sec and 7.5 sec
085501936a.doc
Downloaded from
www.Manualslib.com
Bit7 Bit6
0
0
0
0
0
0
0
1
0
1
0
1
1
0
1
0
1
0
1
1
1
1
1
1
"No function" mode
„Fixed flash" mode
78
is transferred
dec
"Random flash" mode
148 = 10010100
] + random value * [100
bin
----constant----
----random-----
manuals search engine
Dimmer value
Bit5
...
bit0
dez
0 0 0 0 0 0
0
...
...
1 1 1 1 1 1
63
0 0 0 0 0 0
64
...
...
1 1 1 1 1 1
127
0 0 0 0 0 0
128
...
...
1 1 1 1 1 1
191
0 0 0 0 0 0
192
...
...
1 1 1 1 1 1
255
t
= (5 + Dimmer value - 64) * 0.1sec.
Flash
is transferred
bin
]) * 0.1sec.
bin
9 / 28
Hex
Function
00
...
No triggering of flash
3F
40
Bit0..Bit5 sets the flash spacing
...
in 64 stages
7F
80
Bit0..Bit2 sets the spread of the
random part
...
Bit3..Bit5 sets the constant part
of flash spacing
BF
C0
To trigger the flash the trigger
...
threshold 223-224 must be
exceeded
FF
30084-040-1a
