Recommendations – WiFi
WiFi access point – ZAPTEC Pro supports WiFi types b, g and n (2.4 GHz). Most
routers nowadays support 2.4 and 5 GHz. ZAPTEC Pro needs 2.4 GHz.
Installation requirements: The positioning of the WiFi access point can have a dramatic
effect on the signal strength and performance. Get in touch with your network partner in
order to identify the best location.
Make sure that 2.4 GHz is enabled so that ZAPTEC Pro can make a network
•
connection.
Configure a static channel 1, 6 or 1 1 to avoid interference between channels when
•
several access points are used.
Make sure your router is not set to select channels automatically.
•
ZAPTEC recommends fitting and installing the WiFi access point or points as
recommended by the manufacturer in order to achieve optimum signal coverage and
performance.
Power grid
WiFi router or
access point
Connect as many as possible to the Wi-Fi network. If the Wi-Fi signal strength is below -75 dBm, use a PLC on the
i
device in question. The scale goes from -40 to -80. Select a device with a strong Wi-Fi signal strength to act as a
gateway.
4G 4G
Internet connection
Channel 1 – 11
4G 4G
-67 dB
-60 dB
2,4 GHz
-50 dB
Min. -65 dB
-30 dB
4G
-70 dB
-80 dB
-90 dB
