Pet Mate CAT MATE Einbauanleitung

WALL LINER FITTING INSTRUCTIONS
For use with the CAT MATE Lockable Cat Flap with Door Liner (Ref 234) and
CAT MATE 4-Way Locking Cat Flap with Door Liner (Ref 235).
EINBAUANLEITUNG FÜR
D
TUNNELELEMENTE
INSTRUCCIONES DE AJUSTE
E
DE LAS GUARNICIONES PARA
MAMPARA
1
174mm
7
(6 / ")
8
165mm
1
(6 / ")
2
5
1
Make a suitably sized hole in wall and line it
with 19mm ( ⁄
3
4
to take screws, as shown in Fig 1. (We
recommend the bottom of the hole is
approximately
stomach.)
2
Determine thickness of wall (t).
3
Determine number of Wall Liners required.
(Use an additional liner for each 50mm (2")
of wall thickness.)
4
Assemble required number of Wall Liners on
internal frame (frame without swinging flap).
Cut length to wall thickness (t) + 6mm (
using a hacksaw, as shown in Fig 4. Use
moulded lines as a guide to ensure a square
cut.
A helpful tip...
To train your pet to use the cat flap, prop it open at first and use food as
an encouragement.
