Spokey VEXOR Montageanleitung Und Bedienungsanleitung Seite 9

LIST OF PARTS - DIAGRAM – P. 51
No. Description
1 counter
2 bolt M5*10L
3 handlebar post
4 front handlebar post cover
5 bolt ST2.9*30L
6 bolt M5*10L
foam handlebar
φ20*5T*590L
7
8 handlebar φ22.2*2T*1310L
9 end cap
10 bolt ST3.9*20L
11 pulse sensor wire
12 pulse sensor
13 flat washer Ф8*Ф19*2T
14 spring washer Ф8.5*Ф13.5*2.5T
resistance adjustment wire (from
15 the counter)
16 rear handlebar post cover
17 knob M8
18 seat
19 seat base
20 sleeve
21 end cap
22 bolt M6*12L
23 knob M16
24 seat post
25 front stabilizer
26 front stabilizer left end cap
27 front stabilizer right end cap
28 transport roll
29 axle φ7.9*34.4
30 front stabilizer base
31 flat washer φ10.5*φ38*3T
32 bolt 3/16"*20L
33 flat washer Ф8*Ф19*2T
34 bolt M8*75L
35 bolt M8*16L
36 spring washer Ф8.5*Ф13.5*2.5T
37 curved washer Ф8*Ф19*2T
PREPARATIONS
1. Before assembly make sure there is enough space.
2. Use the recommended tools.
3. Before assembly check if there are all the parts in the box.
It is recommended that product should be assembled by at least two people
to avoid injuries.
ASSEMBLY INSTRUCTIONS (Drawings – p. 53-56)
Note: Follow the assembly instructions below:
STEP 1 Fix the front (25) and the rear stabilizer (79) with flat washers
Ф8*Ф19*2T (33) and bolts M8*75L (34).
STEP 2 Mount the handlebar.
ASSEMBLY, SETUP AND MAINTENANCE
Qty No. Description
1 38 lower handlebar post cover
4 39 main frame
1 40 sensor holder
1 41 bolt M5*10L
4 42 knob M16
2 43 seat post sleeve
cover
44 drive wheel Ф260
2
1 45 drive belt 440J6
46 crank axle Ф17*176
2
2 47 bolt M6*16L
48 spring washer Ф6.1*1.6T
2
2 48 nut M6*5.5T
50 C-clip Ф15.7*Ф19.4*1T
1
51 wave washer Ф17.5*Ф25*0.3T
1
52 flat washer Ф17.5*Ф25*0.3T
1
1 53 bearing 6203
1 54 resistance engine
1 55 bolt M5*12
56 flat washer Ф5.5*Ф12.5
1
2 57 bolt ST3.9
1 58 nut M8
1 59 bolt M8*55L
60 flat washer Ф8*Ф19*2T
1
1 61 magnets
1 62 resistance control fastening
1 63 spring
1 64 Allen wrench
2 65 plastic insert
2 66 bolt ST3.9*50L
1 67 right cover
68 bolt 3/16"*3/4"
2
2 69 bolt ST2.9*8L
4 70 left crank cover
71 right pedal crank 9/16"
4
4 72 bolt M8*20L
73 right pedal 9/16"
4
74 left pedal 9/16"
4
Qty
1
1
1
2
1
1
1
1
1
4
4
4
2
1
1
2
1
1
1
4
1
1
1
1
1
1
1
2
7
1
6
8
1
1
2
1
1
Most of the assembly equipment listed here has been packed separately,
but some elements come preassembled in certain assembly parts. If it is
required, dissassemble them and assemble again.
Read the instructions of all assembly steps and familiarize with all the
devices installed.
1. Before screwing it, remember to pull through the pulse sensor wires
through the handlebar post.
2. To fix the handlebar (8), place the plastic cover (16) on it and secure it
with the washers (13, 14) and knob (17).
8
No. Description
75 left pedal crank
76 left crank cover
77 left cover
78 rear stabilizer left end cap
79 rear stabilizer
80 rear stabilizer right end cap
81 adjustment wheel
82 stabilizer foot
83 nut M8
84 sleeve Ф10*Ф14*3mm
85 bearing 6000
86 pulley
87 nut M8
88 flat washer Ф8*Ф19*2T
89 spring 0Dφ16*φ2*45n
90 tensioner lever
91 bolt M8*20L
92 flat washer Ф8*Ф19*2T
93 bearing 6000
94 nut 3/8"-26*7T
95 bolt 3/8"-26*3.8T
96 sleeve Ф10*Ф14*3mm
97 flywheel axle Ф11.5*130L
98 power supply
99 bearing 6300
100 flat washer Ф30*Ф34*0.8T
101 bearing 6003
102 bearing Ф35*17
103 flywheel Ф280*32W*8KG
104 small pulley Ф34*8J
105 bearing 6000
106 resistance adjustment wire
resistance adjustment
107 (from the frame)
108 power cord
109 sleeve Ф10*Ф14*11mm
110 wrench 13, 14
111 wrench 13, 14, 15
