Relevant signal timings
Display mode
VESA
US text
Power Macin-
tosh series
Sun Ultra
series
- Recommended resolution for LL-T1520 is 1024 x 768.
- Recommended resolution for LL-T1620 is 1280 x 1024.
- All are compliant only with non-interlaced.
- The monitor can be connected to the following computers that have a DVI standard output terminal
(DVI-D24 pin or DVI-I29 pin) for digital connection. (Note that the display may not appear correctly,
depending on the connected computer.)
LL-T1520: Computers capable of XGA output
LL-T1620: Computers capable of SXGA output
- Frequencies for Power Macintosh and the Sun Ultra series are reference values. To connect, another
adapter (commercially available) may be required.
- If the monitor is receiving timing signals that are not compatible, [OUT OF TIMING] will appear. Follow
your computer's instruction manual to set the timing so that it is compatible with the monitor.
- If the monitor is not receiving any signal (synch signal), [NO SIGNAL] will appear.
The analog RGB input connector pin
(Mini D-sub connector with 15 pins)
Downloaded from www.Manualslib.com
Hsync
640 x 480 31.5kHz
37.9kHz
37.5kHz
800 x 600 35.1kHz
37.9kHz
48.1kHz
46.9kHz
1024 x 768 48.4kHz
56.5kHz
60.0kHz
1152 x 864 67.5kHz
1280 x 960 60.0kHz
1280 x 1024 64.0kHz
80.0kHz
720 x 400 31.5kHz
640 x 480 35.0kHz
832 x 624 49.7kHz
1024 x 768 60.2kHz
1152 x 870 68.7kHz
1280 x 1024 64.0kHz
80.0kHz
1024 x 768 48.3kHz
53.6kHz
56.6kHz
1152 x 900 61.8kHz
1280 x 1024 71.7kHz
manuals search engine
Specifications
Dot
Vsync
frequency ANALOG DIGITAL
60Hz 25.175MHz
72Hz 31.5MHz
75Hz 31.5MHz
56Hz 36.0MHz
60Hz 40.0MHz
72Hz 50.0MHz
75Hz 49.5MHz
60Hz 65.0MHz
75.0MHz
70Hz
75Hz 78.75MHz
75Hz 108.0MHz
60Hz 108.0MHz
60Hz 108.0MHz
75Hz 135.0MHz
70Hz 28.3MHz
66.7Hz 30.2MHz
74.6Hz 57.3MHz
75Hz 80.0MHz
75Hz 100.0MHz
60Hz 108.0MHz
75Hz 135.0MHz
60Hz 64.13MHz
70.4MHz
66Hz
70Hz 74.25MHz
66Hz 94.88MHz
67.2Hz 117.01MHz
No. Function
1 Red video signal input
2 Green video signal input
3 Blue video signal input
4 GND
5 GND
6 For red video signal GND
7 For green video signal GND
8 For blue video signal GND
9 DDC +5V
10 GND
11 N.C.
12 DDC data
13 For Hsync signal input
14 For Vsync signal input
15 DDC clock
26
LL-T1520 LL-T1620
ANALOG DIGITAL
