Battery Replacement Door
Storage & Service
Storage
Turn your UPS OFF: first, engage the ON/Standby Switch and release it to place your
UPS in the "Standby" mode; then set the System Enable Switch* to "DISABLE"; finally,
disconnect the UPS power cord from the wall outlet. If you plan on storing your UPS
for an extended period of time, recharge the UPS batteries once every three months.
Follow steps #1 and #3 in the Installation section and allow the UPS to charge from
4 to 6 hours. If you leave your UPS batteries discharged for an extended period of time,
they will suffer permanent loss of capacity.
* The location of the switch varies by model. See page 3.
Service
If returning your UPS to Tripp Lite, please carefully pack the UPS using the
ORIGINAL PACKING MATERIAL that came with the unit. Enclose a letter describing
the symptoms of the problem. If the UPS is within the 2 year warranty period, enclose
a copy of your sales receipt.

Specifications

Output Capacity (VA/Watts):
Battery Runtime (Half Load/Full Load) Min.:
Battery Recharge Time:
Suggested Circuit:
Approvals:
Output Capacity (VA/Watts):
Battery Runtime (Half Load/Full Load) Min.:
Battery Recharge Time:
Suggested Circuit:
Approvals:
ALL MODELS:
Input Voltage/Frequency (230V/50-60 Hz); On Line Input Voltage Range (168 - 271 Volts); Voltage-Regulated Output Voltage Range
(230V ± 9%); On Battery Output Voltage Range (230V ± 5%); Output Waveform Line Mode (filtered sinewave); Output Waveform Battery Mode
(PWM sine wave); AC Surge Suppression (exceeds IEEE 587 Cat. A & B standards); AC Noise Attenuation (>40 dB); AC Protection Modes
(H to N, H to G, N to G).
Downloaded from www.Manualslib.com
Under normal conditions, the original batteries in your UPS will last
several years.
qualified service personnel. Refer to "Battery Warnings" in the Safety
section on page 2.
personnel should follow this procedure: 1) turn UPS OFF; 2) remove
the battery door located on the front panel; 3) pull batteries partially
out of the case; 4) make a detailed sketch of the batteries and the
polarity, color and connection of all cables; 5) disconnect battery
terminals; 6) dispose of used batteries; 7) reconnect replacement
batteries exactly as original batteries were; 8) push batteries back into
case and replace cover.*
* You may not receive full runtime until your replacement batteries have fully charged.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change.
manuals search engine
Battery replacement should only be performed by
When replacing batteries, qualified service
SMART INT 1400 RM
1400/940
26/10
2-4 hrs.
15 amp
UL, CE
SMART INT 2200 RM XL
2200/1750
29+/13+
2-4 hrs.
20-amp dedicated
UL, CE
SMART INT 2200 RM
2200/1750
29/13
2-4 hrs.
15- or 20- amp dedicated
UL, CE
SMART INT 3000 RM
3000/2400
23+/7+
2-4 hrs.
30-amp dedicated
UL, CE
7
