TYRE TRANSPORTER STAND
˜ Introduction
We congratulate you on the purchase of
your new product. You have chosen a high
quality product. Familiarise yourself with the
product before using it for the first time. In
addition, please carefully refer to the operating
instructions and the safety advice below. Only
use the product as instructed and only for
the indicated field of application. Keep these
instructions in a safe place. If you pass the
product on to anyone else, please ensure that
you also pass on all the documentation with it.
˜ Intended use
The product is intended for the storage of wheel
rims with or without tyres. This product is not
intended for commercial use.
˜ Description of parts
1 Rear axle with brake
2 Chassis
3 Left support bar
4 Right support bar
5 Handle
6 Plate
7 Wheel
8 Lower rod section
9 Upper rod section
10 Shaft for front wheel
11 Stopper
12 Plastic washer
13 Plain washer (Ø 12 mm)
14 Plain washer (Ø 8 mm)
15 Nut (M8)
16 Nut (M6)
17 Pin
18 Screw (M8 x 55 mm)
19 Screw (M8 x 45 mm)
20 Screw (M8 x 40 mm)
21 Screw (M6 x 45 mm)
22 Tread depth gauge
23 Air pressure gauge
24 Tyre protection cover
25 Tyre chips, 4 different colours
26 Wrench
˜ Technical data
Suitable for:
Currently available car wheel rims up to
18 inches (approx. 46 cm).
Common car wheel rims with tyre widths up
to 255 mm.
Material:
Total height:
Weight
(without accessories):
Max. load capacity:
Max. load per disc:
Max. number of wheels:
x 1
˜ Accessories
x 1
Tread depth gauge 22
x 1
Measurement range:
x 1
x 1
Markings:
x 4
Statutory minimum tread depth (1.6 mm)
x 3
Recommended tread depth for winter tyres
x 1
(4 mm)
x 1
Recommended thread depth for summer
x 1
tyres (3 mm).
x 2
The required profile measurements may vary
x 2
by country. Therefore please find out about the
x 2
specific regulations in your country.
x 10
x 4
Air pressure gauge 23
x 3
For easy measurement of air pressure.
x 4
Measurement range:
x 2
x 2
Tyre protection cover 24
x 2
With hook‑and‑loop tape fastening
x 3
Tyre chips 25
In 4 different colours.
Labelling: front left, right front, left rear, right
rear
x 1
x 1
x 1
x 4
x 2
Steel, aluminium,
PP (polypropylene)
approx. 1.2 m
approx. 7.95 kg
100 kg
25 kg
4 tyres
(255/55 R18)
0 to 20 mm.
0.7 to 3.5 bar /
10 to 50 psi
