GETTING STARTED
Placing the unit
To place the device on the floor, first attach the ground stake to the mounting bracket using the supplied
screws. Now the spot can be stuck into the ground and aligned as desired. To align the device, loosen the
fixation screws, adjust the inclination angle and retighten the screws.
You may also fasten the device to a wall or ceiling via the bracket. Always choose screws and plugs which
are suitable for use in your wall/ceiling and have enough holding power. Fasten the device in such way that it
will not fall down. To align the device, release the fixation screws at the mounting bracket, adjust the desired
inclination angle and tighten the fixation screws.
Overhead rigging
WARNING! Risk of injury caused by falling objects
Devices in overhead installations may cause severe injuries when crashing down. Make sure
that the device is installed securely and cannot fall down. The installation must be carried out by
a specialist who is familiar with the hazards and the relevant regulations.
The device may be fastened to a truss or similar rigging structure. The device must never be fixed swinging
freely in the room.
1
The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.
2
Block access below the work area and work from a stable platform when installing the device.
3
Use rigging hardware that is compatible with the structure and capable of bearing the weight of the
device. Please refer to the "Accessories" section for a list of suitable rigging hardware.
4
Secure the device with a safety bond or other secondary attachment. This secondary safety attachment
must be sufficiently dimensioned in accordance with the latest industrial safety regulations and
constructed in a way that no part of the installation can fall down if the main attachment fails. Use the
hole in the bracket for fixation of the safety rope. Fasten the safety rope in such a way that, in the event
of a fall, the maximum drop distance of the device will not exceed 20 cm.
5
To align the device, release the fixation screws at the mounting bracket, adjust the desired inclination
angle and tighten the fixation screws.
6
After installation, the device requires inspections periodically to prevent the possibility of corrosion,
deformation and looseness.
Connection to the mains
The device uses an auto-range power supply that accepts input voltages between 100 und 240 volts.
Connect the device via the mains cable to a grounded mains socket. Thus the unit is switched on. To switch
off the unit, disconnect the power plug.
Notes: Do not connect the unit to the mains voltage via a dimmer. For a more convenient operation, use a
mains outlet which is switchable.
16/20
00126917, Version 1.0
