Ground Stakes x4
M8 x 70mm Coach screw
FA8439
x4
45 °
M8 x 25mm
x4
Large washer
FA7184
x4
Never set the legs of the playset in concrete.
40
50cm
35cm
35cm
Set the stakes in concrete (as shown).
