TP476 Kingswood2 Tower In0476-E 05 15.qxp_TP476 Kingswood2 Tower In0476-E 05 15 14/05/2015 10:24 Page 19
16
17
Level
MW2073
Platform Centre Support 1583mm
FA9784
M6 x 150mm Woodscrew
Use
Deck board
for positioning
MW2072
5mm x 100mm Woodscrew x2
FA9761
565mm
19
x1
x2
SSEMBLY TIP
15mm
Ladder Support 1111mm
x1
90°
TP Kingswood2 Tower
