TP476 Kingswood2 Tower In0476-E 05 15.qxp_TP476 Kingswood2 Tower In0476-E 05 15 14/05/2015 10:24 Page 14
10
MW2081
MW2081
Ensure frame
is vertical
as shown...
Balcony Angled Brace 445mm
M8 x 70mm Coach screw
FA8439
MW2081
MW2081
90°
3mm
Hole
Note:
90°
x3
M8 x 100mm Bolt x2
FA8437
x3
M8 x 120mm Bolt x1
FA8434
2x
M8
washers
SSEMBLY TIP
or
Drill
Pilot
...then fully tighten bolts from Stage 9
14
M8 Nylon Insert
M8 x 25mm
Dome Nut
Large washer
FA7184
FA8163
x3
x8
x2
x1
TP Kingswood2 Tower
