TP476 Kingswood2 Tower In0476-E 05 15.qxp_TP476 Kingswood2 Tower In0476-E 05 15 14/05/2015 10:23 Page 10
3
MW2075
M8
M8
120mm
4
Note:
Fully tigthen frame
ensuring MW2062
is vertical to
MW2065 & MW2075
Roof Support Brace 902mm
MW2075
MW2065
x1 M8 x 120mm Bolt x2
FA8434
MW2075
90°
90°
10
M8 Nylon Insert
M8 x 25mm
Dome Nut
Large washer
FA7184
FA8163
x2
x2
Fit Flush
Note:
Do not fully tigthen
TP Kingswood2 Tower
