Rear Deck Board 974mm
x1
Full Length Deck Board 974mm
Note:
Equal
Spacing
MW2092
Deck Board Short 528mm
4.5mm x 40mm Woodscrew x44
x11
FA4517
3mm
20
x4
MW2097
x1
B
397mm
