FUNCTIONAL DESCRIPTION

WARNING:
• Before plugging the machine,
always make sure that the
machine is switched off. Plugging
the machine with the switch on
may cause an unexpected start
resulting in serious personal
injury.
• Never use the machine if power
cable is damaged. Otherwise it
may cause electric shock.
• Do not use the machine if the
switch does not turn it on and
off. Have defective switches
replaced by Makita authorized
service center.
Start/stop lever
To start the machine, press and hold the lock-off button
(13), and then fully pull the start/stop lever (14) and hold
it. Once pulling the start/stop lever, you do not need to
hold the lock-off button.
To stop the machine, simply release the start/stop lever.
Height adjustment
Depending on the condition of the grass, adjust the height
of the cutting tool.
Refer to the table below as rough indication for depth
settings.
Height
Scarifying
For transportation and
+10mm
storage.
Scarifying sensitive lawn.
Dethatching thin layers.
+5mm
The second scarifying
operation in autumn.
Scarifying normal lawn.
0mm Dethatching normal
layer.
Scarifying normal lawn.
-5mm
Dethatching thick layer.
Scarifying rough thick
-10mm lawn.
Dethatching thick layer.
12
Usage
Raking
(Optional accessory)
For transportation and
storage.
Raking sensitive lawn.
Dethatching thin layers.
Raking normal lawn.
Raking rough thick lawn.
Do NOT use for raking
operation.
Do NOT use for raking
operation.
Changing the height
Push in the height adjustment lever (9) towards wheel
axis side, and move it upwards or downwards.
Overload protection
This machine is equipped with overload protection, and it
functions under the following situations:
• The cutting tool becomes clogged because scarified
materials are built up around it.
• The machine is trying to scarify more than the motor
can handle.
• Something hinders the rotation of the cutting tool.
When this protection works, the machine is switched off
automatically.
If it happens, unplug the machine, wait until it cools down,
and remove the cause of the overload before restarting
the machine.
OPERATION
Operation Tips:
• Cut your grass before operation and fertilize after the
operation.
• Adjust the depth of the cutting tool in accordance with
the height of the grass and weather.
• Avoid operating on wet grass. It tends to stick on the
discharge port and other parts of the machine. It may
also cause slip and fall.
• Do not move too fast. Push the machine slowly.
Otherwise discharge port may become clogged and the
motor may overloaded.
• Operate along a line as straight as possible.
• Make slightly overlapping scarified lines. It will maintain
even and smooth surface.
• When a flower bed is included in the operating area,
make a circle or two around the flower bed.
• Be especially careful when turning the machine.
• Do not stay in one position. It damages the grass.
Tips for scarifying:
• Always take the weather into account. Warm, sunny
and wet weather is good for scarifying because the
lawn can recover healthily. On the other hand, avoid
cold, heat, dry weather.
• During spring season scarify the lawn.
• If summer is wet, scarify the lawn in early autumn.
• Refrain from scarifying during period of extremely hot
weather.
• If summer is very dry, do not scarify in autumn.
Tips for raking:
• Plenty amount of air is needed for the area around the
roots of the lawn in order to maintain healthy growth in
spring season.
• It is recommended performing aeration operation on the
lawn every 4 – 6 weeks in accordance with the state of
the lawn.

MAINTENANCE

CAUTION:
• Always be sure that the machine
is switched off and unplugged
before performing inspection or
maintenance.
