WARNING:
• This machine produces an
electromagnetic field during
operation. I t i s r ecommended t hat
persons with medical implants
should consult their doctors and
implant manufacturers before
using this machine. Otherwise
the electromagnetic field may
affect medical implants and it
may result in serious injury.
ASSEMBLY
CAUTION:
• Always be sure that the machine
is switched off and unplugged
before carrying out any work on
the tool.
Assembling the handle bar (Fig. 2, 3, 4)
1) Insert the lower handle bar (6) into the support (7).
Align the screw holes on them, and then fasten them
by a screw. Perform this step on both sides.
2) Place the middle handle bar (5) onto the lower handle
bar (6). Align the screw holes of those handles, and
then fasten them with the knob (4), spacer, and the
bolt. Perform this step on both sides.
3) Place the upper handle bar (3) onto the middle handle
bar (5). Fasten each side of the upper bar with the
knob (4), spacer, and the bolt.
4) Fasten the cord with the clips (12) onto the handle bar.
Assembling the grass catcher
CAUTION:
• Do not operate the machine
without grass catcher. Otherwise
ejected object may cause injury.
• For rear discharge appliances
with exposed rear rollers, when
used without a catcher, full eye
protection shall be worn.
NOTE:
• The performance of the machine reduces when the
grass catcher is full. Empty the grass catcher on regular
basis before it becomes completely full.
Installing the grass catcher
Pull up the deflector guard (10) and hold it. Insert hooks
on the grass catcher into the grooves on the machine.
Removing the grass catcher
Pull up the deflector guard (10) and hold it. Remove the
grass catcher by releasing the hooks from the grooves
on the machine.
Cord strain relief (Fig. 5)
The cord strain relief (2) helps to prevent the cord from
entangling into the blade or wheel.
Make a small loop at the end of the mains cord, and pass
it through the opening of the cord strain relief, and then
hang it on the hook.
Always take the position of the cord into consideration
during operation. Start your operation from the nearest
point to the power supply to prevent the cord from
accidentally cut. It is recommended keeping the cord over
your shoulder during the operation.
Removing or installing cutting tool
CAUTION:
• Wear protective gloves.
• Pay particular attention when
handling cutting tool. It is very
sharp and may become hot
during operation.
• Always use appropriate cutting
tool in accordance with your
operation.
• Before operation, make sure
two bolts, which hold the cutting
tool onto the machine, are
firmly tightened. Do not use the
machine if it is loose or missing.
If it is damaged, replace it
immediately.
Removing cutting tool
1) Remove the grass catcher (11).
2) Remove the handle from the machine.
3) Place the machine upside down on a flat surface.
4) Loosen the two bolts (16). Remove them and spring
washers.
5) Lift the bearing part of the cutting tool (17), and then
pull the cutting tool (15) out from the drive shaft (18).
Installing the cutting tool
1) Insert the cutting tool by sliding its hex nut part into the
socket of driving shaft.
2) Fasten the bearing part to the machine by the bolts
and spring washers.
11
